Inconel 601
UNS N06600 / W.Nr. 2.4816
Engineered for extreme environments, Inconel 600 delivers outstanding resistance to heat, oxidation, and corrosion. Manufactured with strict metallurgical control, ZHONGXIN provides reliable nickel alloy materials for critical industrial applications where performance, durability, and long service life are essential
inconel 600 type
Premium Nickel Alloy Solutions
ZHONGXIN supplies Inconel 600 in a full range of product forms including tubes, pipes, sheets, plates, bars, wires, and precision fittings.
Each product is manufactured according to international standards and designed to support demanding industries.
inconel 600 tubes&pipes
- Seamless Pipe & Tube
- Capillary Tube
- Thick-walled Pipe
- Welded Pipe & Tube
- Coil Tube
inconel 600 wires
- Wire Rod
- Welding Electrode
- Wire
- Filler Metal
inconel 600 sheets
- Sheet
- Coil
- Plate
- Strip
inconel 600 bars
- Round Rod
- Square Bar
- Flat Bar
- Hexagon Bar
inconel 600 fittings
- Elbow
- Reducer
- Pipe Cap
- Flange
- Tee
Custom Bike Builder
Inconel 600 Introduction
Inconel 600 is a nickel chromium alloy strengthened through solid solution metallurgy, delivering exceptional resistance to oxidation, carburization, and chloride stress corrosion cracking. ZHONGXIN ensures precise alloy composition and strict production control to guarantee consistent mechanical performance and long term stability in aggressive operating conditions.
Solid Solution Strengthened Alloy
Corrosion Resistance
Mechanical Behavior
Purity
As a leading supplier & manufacturer in China, ZHONGXIN supply cost-effective Inconel 600 Products.
INCONEL® (nickel-chromium-iron) alloy 600 (UNS N06600 / W.Nr. 2.4816) is a standard engineering material for applications which require resistance to corrosion and heat. The alloy also has excellent mechanical properties and presents the desirable combination of high strength and good workability.
The high nickel content gives the alloy resistance to corrosion by many organic and inorganic compounds and also makes it virtually immune to chloride-ion stress-corrosion cracking. Chromium confers resistance to sulfur compounds and also provides resistance to oxidizing conditions at high temperatures or in corrosive solutions. The alloy is not precipitation hardenable; it is hardened and strengthened only by cold work.
The versatility of INCONEL alloy 600 has led to its use in a variety of applications involving temperatures from cryogenic to above 2000°F (1095°C).
The alloy is used extensively in the chemical industry for its strength and corrosion resistance. Applications include heaters, stills, bubble towers and condensers for processing of fatty acids; evaporator tubes, tube sheets and flaking trays for the manufacture of sodium sulfide; and equipment for handling abietic acid in the manufacture of paper pulp.
The alloy’s strength and oxidation resistance at high temperatures make it useful for many applications in the heat-treating industry. It is used for retorts, muffles, roller hearths and other furnace components and for heat-treating baskets and trays.
In the aeronautical field, INCONEL alloy 600 is used for a variety of engine and airframe components which must withstand high temperatures. Examples are lockwire, exhaust liners and turbine seals. INCONEL alloy 600 is used in the electronic field for such parts as cathode-ray tube spiders, thyratron grids, tube support members and springs.
The alloy is a standard material of construction for nuclear reactors. It has excellent resistance to corrosion by high-purity water, and no indication of chloride-ion stress-corrosion cracking in reactor water systems has been detected. For nuclear applications, the alloy is produced to exacting specifications and is designated INCONEL alloy 600T.
In the annealed condition, the alloy exhibits moderate yield strengths of 25,000 to 50,000 psi (172 to 345 MPa). Yield strengths in that range, combined with elongations of 55 to 35%, permit the alloy to be fabricated with little difficulty. Heavily coldworked material, however, can have tensile strengths as high as 220,000 psi (1517 MPa).
Values for properties reported in this publication are typical but are not suitable for specification purposes unless stated as minimum or maximum.
The composition of Inconel alloy 600 enables it to resist a variety of corrosives. The chromium content of the alloy makes it superior to commercially pure nickel under oxidizing conditions, and its high nickel content enables it to retain considerable resistance under reducing conditions. The nickel content also provides excellent resistance to alkaline solutions.
The alloy has fair resistance to strongly oxidizing acid solutions. However, the oxidizing effect of dissolved air alone is not sufficient to insure complete passivity and freedom from attack by air-saturated mineral acids and certain concentrated organic acids.
Strength &
Stability
Oxidation
Resistance
Carburization
Resistance
Sulfidation
Resistance
Nitriding
Resistance
Carbonitriding
Resistance
Resistance to
Molten Salts
Sulfuric
Acid
Hydrochloric
Acid
Hydrofluoric
Acid
Phosphoric
Acid
Nitric
Acid
Organic
Acids
Alkalies
and Salts
Seawater
Custom Bike Builder
Inconel 600 Chemical Composition
Accurate chemical balance is essential for the performance of nickel based alloys. ZHONGXIN maintains strict control of elements such as nickel, chromium, iron, and trace components during melting and refining processes, ensuring superior corrosion resistance, structural stability, and reliable mechanical strength across diverse industrial environments.
Custom Bike Builder
Inconel 600 Data Sheet
ZHONGXIN provides detailed physical and mechanical data to support accurate engineering calculations and material selection. Key parameters including density, melting range, tensile strength, yield strength, and thermal properties are verified through rigorous testing to ensure dependable performance in high temperature and corrosive service conditions.
Physical Properties
| Density | g/cm3 | 8.47 | |
|---|---|---|---|
| lb/in.3 | 0.306 | ||
| Melting Range | °F | 2470 – 2575 | |
| °C | 1354 – 1413 | ||
| Specific Heat | Btu/lb-°F | 0.106 | |
| J/kg-°C | 444 | ||
| Electrical Resistivity | ohm-circ mil/ft | 620 | |
| μΩ-m | 1.03 | ||
| Curie Temperature | °F | -192 | |
| °C | -124 | ||
| Permeability at 200 oersted | 15.9 kA/m | 1.010 | |
Mechanical Properties
| Form and Condition | Tensile Strength | Yield Strength (0.2% Offset) | Elongation, % | Hardness, Rockwell | ||
|---|---|---|---|---|---|---|
| ksi | MPa | ksi | MPa | |||
| Rod and Bar | ||||||
| Cold-Drawn | ||||||
| Annealed | 80-100 | 550-690 | 25-50 | 170-345 | 55-35 | 65-85B |
| As-Drawn | 105-150 | 725-1035 | 80-125 | 550-860 | 30-10 | 90B-30C |
| Hot-Finished | ||||||
| Annealed | 80-100 | 550-690 | 30-50 | 205-345 | 55-35 | 65-85B |
| Hot-Finished | 85-120 | 585-830 | 35-90 | 240-620 | 50-30 | 75-95B |
| Plate | ||||||
| Hot-Rolled | ||||||
| Annealed | 80-105 | 550-725 | 30-50 | 205-345 | 55-35 | 65-85B |
| As-Rolled | 85-110 | 580-760 | 35-65 | 240-450 | 50-30 | 80-95B |
| Sheet | ||||||
| Cold-Rolled | ||||||
| Annealed | 80-100 | 550-690 | 30-45 | 205-310 | 55-35 | 88B max. |
| Hard | 120-150 | 830-1035 | 90-125 | 620-860 | 15-2 | 24C min. |
| Strip | ||||||
| Cold-Rolled | ||||||
| Annealed | 80-100 | 550-690 | 30-45 | 205-310 | 55-35 | 84B max. |
| Spring Temper | 145-170 | 1000-1170 | 120-160 | 830-1100 | 10-2 | 30C min. |
| Tube and Pipe | ||||||
| Hot-Finished | ||||||
| Hot-Finished | 75-100 | 520-690 | 25-50 | 170-345 | 55-35 | – |
| Annealed | 75-100 | 520-690 | 25-50 | 170-345 | 55-35 | – |
| Cold-Drawn | ||||||
| Annealed | 80-100 | 550-690 | 25-50 | 170-345 | 55-35 | 88B max. |
| Wire | ||||||
| Cold-Drawn | ||||||
| Annealed | 80-120 | 550-830 | 35-75 | 240-520 | 45-20 | – |
| No.1 Temper | 105-135 | 725-930 | 70-105 | 480-725 | 35-15 | – |
| Spring Temper | 170-220 | 1170-1520 | 150-210 | 1035-1450 | 5-2 | – |
Submit Material Specifications
Provide material grade, size, standard and quantity requirements. Drawings or technical documents can also be included for special components or custom fabricated parts.
Receive Technical Review & Quotation
Within a short response time, ZHONGXIN provides a detailed quotation together with technical confirmation. The engineering team reviews standards, dimensions, tolerances and production methods to ensure accuracy before manufacturing begins.
Order Confirmation & Production
After technical approval and order confirmation, production is scheduled according to the agreed specifications and standards.
Shipping & Delivery
Your project enters our manufacturing queue the morning after we receive your approval. On average, custom orders ship within 30-45 business days. In stock products and samples ship within 48 hours.
Just 4 Steps
Custom Inconel 600 Quotation Process
From inquiry to shipment, ZHONGXIN simplifies the sourcing process for nickel alloy materials. Professional engineers evaluate specifications, provide technical recommendations and ensure every order meets strict industry standards.
Manufactured According to Global Industry Standards
Inconel 600 Standards
ZHONGXIN produces Inconel 600 materials in compliance with internationally recognized standards including ASTM, ASME, and AWS specifications. These standards ensure dimensional accuracy, chemical composition consistency, and reliable mechanical properties required by industries operating in highly demanding environments.
ASTM B163
Condensor and Heat Exchanger Tube
ASTM B167
Seamless Pipe & Tube
ASTM B829
Seamless Pipe & Tube
ASTM B517
Welded Pipe
ASTM B775
Welded Pipe
ASTM B516
Welded Tube
ASTM B751
Welded Tube
ASTM B366
Welded Fittings
ASTM B166
Rod, Bar and Wire
ASTM B564
Forgings
ASTM B168
Plate, Sheet and Strip
ASTM B906
Plate, Sheet and Strip
AWS A5.14 ERNiCr-3
Filler Metal
AWS A5.11 ENiCrFe-3
Welding Electrode
AWS A5.11 ENiCrFe-3
Welding Electrode
Designed for High Temperature and Corrosive Environments
Inconel 600 Applications
Due to its outstanding resistance to oxidation and corrosion, Inconel 600 is widely applied in petrochemical processing, marine engineering, power plants, aerospace systems, and heat treatment equipment. ZHONGXIN nickel alloys are engineered to maintain structural integrity and long service life under extreme operational conditions.
Precision Manufacturing from Raw Material to Final Inspection
From Design to Quality Control
Every Step Tailored to Perfection
ZHONGXIN applies advanced metallurgical processing including vacuum melting, hot rolling, cold drawing, precision machining, and strict quality inspection. Every stage of production is controlled to ensure consistent microstructure, dimensional accuracy, and reliable mechanical performance for demanding industrial applications.
- RX Feugiat 2000
- 4-5 months
- $ 8,400
Explore the Complete Inconel Alloy Series
More Inconel Grades +
ZHONGXIN offers a comprehensive portfolio of Inconel alloys including grades such as 601, 617, 625, and 602CA. Each alloy grade is optimized for specific performance requirements including enhanced oxidation resistance, improved creep strength, or superior corrosion protection across various industrial sectors.
600
Si
C
Mn
Cu
Fe
Cr
Ni
601
Si
C
Mn
Al
Cu
Fe
Cr
Ni
601GC
Si
Mn
Al
Cu
Fe
Cr
Ni
602CA
Si
C
Al
Y
Fe
Cr
Ni
603XL
Si
C
Al
Ti
Mo
Cr
Ni
617
Si
C
Mn
Al
Ti
Cu
Co
Mo
Fe
Cr
Ni
625
Si
C
Al
Ti
Co
Ta
Mo
Fe
Cr
Ni
625LCF
Si
Al
Ti
Co
Ta
Mo
Fe
Cr
Ni
686
Mn
W
Mo
Fe
Cr
Ni
690
Si
Cu
Fe
Cr
Ni
693
Si
C
Mn
Al
Ti
Cu
Nb
Fe
Cr
Ni
706
Si
Al
Ti
Co
Nb
Fe
Cr
Ni
718
Si
C
Al
Ti
Co
Nb
Ta
Mo
Fe
Cr
Ni
718SPF
Si
Al
Ti
Co
Nb
Mo
Fe
Cr
Ni
725
Si
Al
Ti
Nb
Mo
Fe
Cr
Ni
740H
Si
Mn
Al
Ti
Cu
Co
Mo
Fe
Cr
Ni
X-750
Si
C
Mn
Al
Ti
Cu
Co
Fe
Cr
Ni
751
Si
C
Mn
Al
Ti
Cu
Co
Fe
Cr
Ni
MA754
Al
Ti
Fe
Cr
Ni
MA758
Al
Ti
Fe
Cr
Ni
783
Si
Al
Ti
Cu
Co
Nb
Fe
Cr
Ni
Professional Insights on Nickel Alloy Materials
Inconel 600 Nickel Alloy Knowledge
ZHONGXIN shares in depth technical resources covering nickel alloy comparisons, material selection guidance, and engineering application insights. These knowledge resources help engineers and buyers better understand alloy characteristics and choose the most suitable materials for complex industrial environments.
